Compression
(Single Channel) |
MJPEG |
| Storage space: 12K-20K/Frame |
| Video Input/ Output |
NTSC: 4 Channel BNC Input/1 Channel BNC Output |
| PAL : 4 Channel BNC Input/1 Channel BNC Output |
| Display Frame Rate |
NTSC: 120 FPS（4 x 30 FPS） |
| PAL : 100 FPS（4 x 25 FPS） |
| Record Frame Rate (Quad Mode) |
NTSC : Max 30 FPS 640 x 224 |
| PAL : Max 25 FPS 640 x 272 |
| Record Frame Rate (Full Screen Mode) |
NTSC : Max 7.5 FPS 320x 112 |
| PAL : Max 6.25 FPS 320x 136 |
| Record Mode |
Manual, Schedule, Motion Detection |
| Playing Mode |
1 Channel or 4 Channel |
| Searching Mode |
By Time/ By Date/ By Event |
| HDD |
Includes 500GB SATA Hard Drive |
| Remote Control |
Yes |
| Alarm |
Video Lost Alarm |
| USB Port |
USB2.0 |
| Language Support |
Simplified Chinese，English |
| 7 Inch Hidden TFT Monitor |
NO |
Hidden TFT Monitor |
Fixed TFT Monitor |
| Cameras’ remote power supply |
Supply Remote Power for 4 channel cameras Distance:50m.
DV12V 300mA |
| Power Supply |
12V/ 4A DC |
12V/ 5A DC |
| Working Temperature |
-10℃ - +50℃ |
| Working Humidity |
10% - 90% |
| G.W/ N.W |
3.5KG/2.1KG |
6.1KG/4.5KG |
5.0KG/3.2KG |
| Meas (Lx Wx H) |
330x 230x 60mm |
330x 360x 60mm |
200x 130x 230mm |
